44 Must-know Olmo Alpic OS-24ALP230VGF A/C Specs
24000
BTU
cooling
24000
BTU
heating
32
db
Min. Noise
Our Score: 92%
| Release month | 03 |
| Release quarter | 01 |
| Basics | |
|---|---|
| Main category | Split air conditioner |
| SERIES | Alpic |
| Weight | 29.3lbs. (117.1 lbs for outdoor unit) |
| Weight lbs with package | 36.6 (124.6 lbs for outdoor unit) |
| Height (inches) | 8.66 (14.29 inches for outdoor unit) |
| Width x Height | 40.87-inch wide x 8.66 (14.29 inches for outdoor unit)-inch high (33.27 inches for outdoor unit) |
| Depth | 12.8 inches (27.64 inches for outdoor unit) |
| Width (mm) | 1038.1 |
| Height (mm) | 220 |
| Depth (mm) | 325.1 |
| Cooling system | Inverter technology |
| Energy Efficiency | |
| Energy efficiency ratio (EER) | 9 |
| Seasonal Energy efficiency ratio (SEER) | 15 |
| Coefficient of Performance (CoP) | 2.76 |
| Heating seasonal performance factor (HSPF) | 8.8 (for HSPF4, 7.4 for HSPF 5) |
| Refrigerant charge (oz) | 63.5 |
| Functions | |
| Air deflection | ? (auto-swing function) |
| Automatic setting |  |
| Dehumidifier Specs | |
| Lowest operation temperature (F) | 63 °F (32F for heating, 50F for drying) |
| Lowest operation temperature (C) | 17 °C (0C for heating, 10C for drying) |
| Highest operation temperature (F) | 90 °F (86F for heating, 90F for drying) |
| Highest operation temperature (C) | 32 °C (30C for heating, 32C for drying) |
| Performance | |
| Cool BTU rating | 24000 BTU |
| Compressor features | Anticorrosion Gold Fin coating |
| Heat BTU rating | 24000 |
| Compressor type | Rotary |
| Air fan speeds | ? (They mention multiple fan speeds and a fan delay option) |
| Air flow | 565CFM (16.00 cubic metre/min.) (565/447/341 CFM) |
| Amps | 11.8 (11.3A for heating) |
| Voltage | 230 (208 to 230V, at 60Hz) |
| Min. noise level | 32dBA |
| Max. noise level | 45dBA |
| Max. noise level (outdoors) | 58.5dBA |
| Convenience | |
| Auto restart | |
| Other Specs & Features | |
| Certifications | AHRI |
| Preset programs | Sleep Mode, Cool, Heat, Self-diagnosis |
| Release year | 2018 |
| Refrigerant | R410A |
| Special Included Accessories | 16AWG4 stranded and unshielded wires, 25-feet pre-charge |
| Available colors | White |
| Display Type | Body-integrated White LED |
| Manufacture product ID | OS-24ALP230VGF/I (OS-24ALP230VGF/O for outdoor unit) |
Description:
Also known as: Olmo OS-24ALP230VGF, Olmo Alpic 24000 BTU Ductless AC with Heat, Olmo Alpic 24000 BTU Mini Split Air Conditioner with Hear.
