Complete Lawn-Boy 17734 Mower Specs
21
-inch
cutting width
Our Score: 83%
| Under The Hood | |
|---|---|
| Engine Make | Kohler |
| Engine Model | XTX |
| Engine Type | OHV |
| Cylinder displacement | 149 cc |
| Engine fuel | Non-ethanol gasoline with an octane rating of at least 87 |
| CARB compliant |  |
| Gross Torque | 6.5 foot-lbs (Lawn-Boy says that because of safety requirements, the commercially available 17734 was configured to have a "significantly lower" torque) |
| Mowing Features | |
| Cutting width (inches) | 21 (This is the deck's width. Actual cutting width may be less) |
| Cutting methods |
|
| Cutting deck material | Steel |
| Grass bag capacity (L) | 70.48 |
| Mower Cut Height (inches) | 3.75 |
| Mower Cut Height Min (inches) | 1.25 |
| Cut Height Increments count | 6 |
| Cutting height adjustment | Dual-lever-operated |
| Drive Details | |
| Drive system type | Self-propelled (RWD) |
| Forward Speeds | ? (variable) |
| Wheel type | Rubber |
| Front Wheel Diameter | 7 x 7 inches |
| Rear Wheel Diameter | 8 x 8 inches |
| Other Specs & Features | |
| Handle Type | Adjustable |
| Claimed qualities | Lawn-Boy claims that the 17734 does not need an oil change |
| Model Variants | 17332 (This one has a recoil start) |
| Starter type | Turn the key (electric) |
| AlphaMetrics | |
| Release year | 2015 |
| Release month | 04 |
| Width (inches) | 22.3 |
| Height (inches) | 37.7 |
| Depth (inches) | 40.5 |
| Width (mm) | 566.4 |
| Height (mm) | 957.6 |
| Depth (mm) | 1028.7 |
| General Specs | |
| Main category | Walk-behind lawn mower |
| Weight | 75lbs. |
| Weight lbs with package | 99.2 |
| Warranty | 2 years |
Description:
Also known as: Lawn-Boy 21" 149cc Lawn Mower.
